In terms of function, the wall breaking machine integrates the functions of juicer, soybean milk machine, cooking machine, grinder, and noodle machine, which greatly improves the scope of application of the product, and is the first choice for modern home health care and health. At present, the high-end wall breaking machine is mostly controlled by PMSM motor, which has smaller volume, higher speed, lower working noise, stronger wall breaking ability and wider speed regulation range.

Topological graph

Recommend Part No.

Switching power supply：

VDS=650V-700V    Ron@10V（max）=360mΩ-1100mΩ

LC65R380  LC65R900  LC65R1K0  LC65R600

Motor drive：

600V-650V IGBT：ID=7A-40A

LGT15N65 LGT20N65 LGT30N65 LGT40N65
